ME-50-104 Precised Filter Element

Professional ME-50-104 Precised Filter Element Quotation. ME-50-104 precised filter element is processed by filter material made of wood pulp, cellulose and additives. Segmented rolling manufacturing process is adopted to press the filter material of the planar structure into a cylindrical filter element with different density gradients. The filter element has the following functions, such as absorbing pollutants by grades, adsorbing pollutants, and absorbing and locking moisture.

Model number: ME-50-104

Outer diameter (mm): Φ145

Inner diameter (mm): Φ38

Height (mm): 104

Maximum impurity absorption (approximately): 350 g

Maximum water absorption (approximately): 690 mL

Temperature range in operation: 0～80℃

Viscosity range of the used oil: 9～180cSt

Supporting bypass oil filter model: BU-50-104

a. High filtering accuracy, the oil cleanliness level after filtration is as high as NAS3

b. Large dirt holding capacity, with the three functions of adsorption, subsumption and water absorption at the same time

c. It can filter out moisture, oil oxides, sludge and micron solid particles

ME-50-104 precised filter element is suitable for precised filtration of hydraulic oil and other industrial oils with a viscosity ranging from 9 to 180cSt. It has excellent filtering effects for oils of different pollution levels.

•

  （AAA-grade credit enterprise）

•

  （Guangdong Province Contract-abiding and Credit-worthy Enterprise）

A: As long as you are engaged in related business in the hydraulic industry with corresponding technical personnel, you can apply for an agency from us.

A: For customers of foreign countries, we do not provide on-site installation services for the time being. Product installation is relatively simple. We will provide simple and easy-to-understand installation instructions. If necessary, we can provide related installation videos before installation.

A: Generally we have stocks. If there is no stock, the production cycle will take about two working weeks.
