BU-32 Bypass Oil Filter
  • BU-32 Bypass Oil FilterBU-32 Bypass Oil Filter
  • BU-32 Bypass Oil FilterBU-32 Bypass Oil Filter

BU-32 Bypass Oil Filter

China Advanced BU-32 Bypass Oil Filter Manufacturers, we have an annual sales volume of more than 30,000 units. The BU-32 bypass oil filter can filter micron-level pollutants with high filtering accuracy and affordable price.

Send Inquiry

Product Description

1. Product Introduction of BU-32 Bypass Oil Filter

China Advanced BU-32 Bypass Oil Filter Manufacturers. The BU-32 bypass oil filter is used in combination with the hydraulic system, and uses the pressure of the hydraulic system to divert a certain amount of oil from the hydraulic oil circuit, and then performs bypass precised filtration through the oil filter. The BU-32 bypass oil filter and the hydraulic system are operated at the same time to remove the oil contaminants generated by the hydraulic system in real time, improve the oil cleanliness level, greatly extend the service life of the oil, reduce the failure rate of the hydraulic system, and maintain the hydraulic system in good working condition.

2. Technical parameters of BU-32 bypass oil filter

Product model: BU-32

Supporting filter model: ME-32

Flow rate: 1.5L/min

Filtering accuracy: μ level

The highest cleanliness grade: NAS6

Maximum water removal amount: about 0.46L

Maximum decontamination amount: about 600g

Applicable pressure range: 0.6~21Mpa

Oil temperature range: 0~80℃

Oil viscosity range: 9~180cSt

Inlet and outlet diameter: RC1/4

Weight (kg): 2.7

Dimensions (mm): 140x122x285

Applicable fuel tank capacity: ≤120L

BU-32 Bypass Oil Filter

3. Product features of BU-32 bypass oil filter

The BU-32 bypass oil filter can filter out oil oxides, sludge, moisture and micron solid particles. The built-in safety valve can avoid damage to the oil filter due to excessive pressure. The prompt of filter element saturation alarm can be customized, it is intelligent and convenient, and the maintenance is worry-free. The BU-32 bypass oil filter can be used together with injection molding machines, die-casting machines, hydraulic machine tools, hydraulic stations and other hydraulic machinery and equipment.

BU-32 Bypass Oil Filter

4. Picture of BU-32 bypass oil filter after use

The filter element of BU-32 bypass oil filter is made of wood pulp, cellulose and additives. It has three functions: water absorption, adsorption and subsumption.

BU-32 Bypass Oil Filter

5. Company certificates

  • BU-32 Bypass Oil Filter

    (Guangdong Province Contract-abiding and Credit-worthy Enterprise)
  • BU-32 Bypass Oil Filter

    (AAA-credit enterprise)

FAQ

Q: How can I be your agent?

A: As long as the company is engaged in relevant businesses in the hydraulic industry and has corresponding technicians, it can apply for agency with us.


Q: Can you send your staff to our factory to install equipment for us?

A: For customers of foreign countries, we do not provide on-site installation services for the time being. Product installation is relatively simple. We will provide simple and easy-to-understand installation instructions. If necessary, we can provide related installation videos before installation.


Q: How long is the production cycle?

A: Generally we have stocks. If there is no stock, the production cycle will take about two working weeks.
